Additional data
|
| Cutting disc diameter |
355 mm |
| Cutting disc bore |
25.4 mm |
| No-load speed |
3,800 rpm |
| Rated input power |
2,200 W |
| Cutting capacity at rectangle 0º |
100 x 196 mm |
| Cutting capacity at square 0º |
119 x 119 mm |
| Cutting capacity at L-profile 0º |
130 x 130 mm |
| Cutting capacity at rectangle 45º mitre |
107 x 115 mm |
| Cutting capacity at square 45º mitre |
110 x 110 mm |
| Cutting capacity at L-profile 45º mitre |
115 x 115 mm |
| Tool dimensions (width x length x height) |
256 x 520 x 400 mm |
| Weight |
15 kg |
Total vibration values (Cutting metal)
|
| Vibration emission value ah |
2.5 m/s² |
| Uncertainty K |
1.5 m/s² |
Noise/vibration information
|
| Sound pressure level |
100.5 dB(A) |
| Sound power level |
113 dB(A) |
| Uncertainty K |
3 dB |
Cutting metal
|
| Vibration emission value ah |
2.5 m/s² |
| Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
